RFCOM-508 All-Purpose 4G Industrial Gateway

The RFCOM-508 industrial gateway is a high-performance communication device specifically designed for industrial Internet of Things (IIoT) scenarios, equipped with a domestic high-performance ARM processor. Supports interfaces such as S485/CAN/DIDO/ Ethernet; Integrating multi-protocol conversion, edge computing and industrial-grade protection, it provides a stable and reliable connection solution for remote monitoring, intelligent control and data interaction. It is widely applied in fields such as intelligent manufacturing, energy and power, and smart cities, helping enterprises achieve digital and intelligent upgrades of equipment and build an efficient and reliable industrial Internet of Things ecosystem.

consult

After-sales service email：service@cloudnineinfo.com

After-sales service hotline：400-6628-128

  • Domestic high-performance and strong computing power

    Equipped with the RK3568J quad-core 1.8GHz processor, it has a computing power of 1TOPS, meeting the requirements of edge computing and intelligent control.

  • The interface is rich and has strong scalability

    It provides a Gigabit Ethernet port, multiple RS485/CAN and DI/DO channels, and supports M.2 SSD expansion, with outstanding connection and storage capabilities.

  • Industrial-grade high-reliability design

    Wide temperature and wide voltage (16-32V DC, -20 to 70℃), fanless heat dissipation, ensuring long-term stable operation in complex industrial environments.

  • Convenient remote operation and maintenance management

    Support WEB remote configuration, online upgrade and message viewing to improve operation and maintenance efficiency.

Application scenario

  • Smart energy

  • Intelligent manufacturing and industrial automation

  • Smart City

  • Robot
    Technical specification
    Name Specifications
    System
    CPU RK3568J，32Bit
    Operating system Debian
    Storage DDR4:4GB；EMMC:32GB；SSD（256/512/1024GB Optional）
    LED System: Power*1，RUN*1
    LAN : 1000M*3(Link*1，Act*1)
    Others RTC/Hardware watchdog
    Overall machine characteristics
    Weight 1.53kg(No ear loops)
    Size 252mm*159mm*33mm
    Input voltage DC:16-32V
    Power consumption (static) ＜5W
    Power consumption (full load ＜10W
    Working environment temperature -25～65℃
    Relative humidity of the working environment (non-condensation) 5%～95%(No condensation）
    Certification test
    ESD GB/T 17626.2-2018 Contact: 6KV, air: 8KV
    EFT GB/T 17626.4-2018 Class 3
    SURGE GB/T 17626.5-2018 Class 3
    RE/CE/RS/CS GB/T 9254.1-2021 Class A
    Software functions
    Communication protocol Support the Modbus RTU communication protocol
    Support Modbus TCP communication protocol
    Supports IEC104 communication protocol
    Communication machine software Support data processing and protocol conversion
    Support modification of network port sorting and IP configuration
    Supports 485 configuration baud rate, supports stop bit and check bit modification, and supports firmware upgrade
    Safety features Support user hierarchical management and password protection
    WEB end function Support IP search for the management machine
    Support IP modification
    Supports login with different permissions and accounts, supports configuration import, and supports configuration summoning
    Support configuration export. COM configuration export /TCP configuration export/point table configuration export supports operation monitoring
